Details
Baling system BM12 takes packaged products from vertical filling machine’s output conveyor. From here the product will be referred to the elevator conveyor. The ironing conveyor on the elevator conveyor, takes over air of the packaged products makes standart forms and measures and transmit it to the filling conveyor. On the filling conveyor by increasing speeds of the packages, packages come in the filling unit. The film installed on the bobbin unit of the machine, on the collar-tube group is turned in to bag. İncoming packets in the filling unit are properly stacked into this bag. By horizontally and vertically bonding the bag brought to bale. Bale is taken out of the machine by conveyor belt. At any time the machine can be upgraded with accessories and devices to respond to the ever changing needs of the market.
General Features:
• Intermittent motion system
• Parts contact with product 304 stainless steel
• Top filling Groups are made of 304 stainless steel
• Servo montion controlled system
• All functions are controlled by 10” HMI colored touch screen.
• Servo controlled film dirve belts
• Easy to setup and operate
• Easy film splicing Unit
• Auto – film unwinding unit with tension control
• Precision and stable continuous horizontal and vertical heat sealing by P.I.D Control System
• Film-drive belt centreing
• Film centering from touch panel
• Feeding conveyor with speed control
• Loading elevator with speed control
• Air outlet punch hole system
• Works with or without Photocell
• Film failure warning system
• Statistics (machine run time, the fault and the amount of production)
• Air pressure control valve
• Phase protection relay
• Emergency stop relay
• Voice, illuminated warning light
• CE standards
