• max. pallet size:

  fp330 = 1200 x 1200 x 2100 mm (wxlxh)

  fp480 = 1200 x 1400 x 2000 mm (wxlxh)

  • max. load capacity:

  fp330 = 1000 kg

  fp480 = 2000 kg

  • table work surface height:

  fp330 = 320 mm

  fp480 = 370 mm

  • air consumption: 80 nl/cycle

  • max. height of usable film reel: 500 mm

  • max. diameter: Film reel: 300 mm

  • photocell for automatic reading of the height of the load to be wrapped

  • electromagnetic clutch for regulating the film tension

  • reel carriage transmission via belt

  • cycle start via radio control

  • hourly production: 25/30 pallets

  • automatic film hooking at the start of the wrapping cycle

  • automatic film cutting at the end of the wrapping cycle

  • predisposition for mounting a pressing unit

  • separate programming of the lower and upper coils (from 1 to 3)

  • programmable logic (Allen Bradley PLC)

  • inverter for gradual start-up, rotation speed regulation and stop in the indexed position of the rotating table

  • machine reset button

  • safety guards, complete with anti-intrusion photocells

  • standard voltage: 380 V – 50 Hz – 3 phase + neutral

  • installed power: 1 kW
